BUILDING ECOLOGY -- MAKING THE CONNECTIONS
You will find example of how air, surfaces, chemicals, and indoor environmental characteristics interact to create the conditions that affect our health, comfort, and well being. Among the important interactions are those of chemicals on surfaces, especially biocides, and the microbes (bacteria, fungi, and viruses) found in the indoor environment and of greatest concern for human health.
Biocides (antimicrobials, pesticides, etc.) are chemicals, often applied to surfaces to kill bacteria, viruses and fungi. If we sample a surface for microbes without any information on the chemicals applied there, we know much less about the indoor microbiome than we need to move toward the creation of healthful indoor environments. Understanding the indoor environment and how it affects our health requires bridging across disciplines and connecting the knowledge each can bring.
How "green" is LEED Platinum?
Of course it depends on how the points were earned for the Platinum rating, your values, and how you define "green." If it's just about energy or climate change (e.g., GHG emissions), then what about other categories, in particular, indoor environmental quality and occupant health, resource consumption, and waste generation?
Or, if most of the points for LEED Platinum were gained from non-energy credits and you value energy conservation highly due, for example, to the potential impact on greenhouse gas emissions or energy resource depletion, then, as the case with the LEED platinum Bank of America Tower in Manhattan, your definition of "green" reflects your implicit (if not explicit) values.
If you value energy performance highly, then Platinum does not necessarily please you or satisfy your criteria for green.
A recent article in Time revealed how energy intensive the digital economy is. Here is a quote from the article that prompted this post:
"Here’s an example: the New Republic recently ran a story arguing that the greenest building in New York City — the Bank of America Tower, which earned the Leadership in Energy and Environmental Design’s (LEED) highest Platinum rating — was actually one of the city’s biggest energy hogs. Author Sam Roudman argued that all the skyscraper’s environmentally friendly add-ons — the waterless urinals, the daylight dimming controls, the rainwater harvesting — were outweighed by the fact that the building used “more energy per square foot than any comparably sized office building in Manhattan,” consuming more than twice as much energy per square foot as the 80-year-old (though recently renovated) Empire State Building."
[Added comment - January 1, 2015: Can you separate plug loads -- e.g. computers, refrigerators, TVs, hair dryers, electric tooth brushes, countertop or built-in microwave ovens -- from building-related loads -- e.g, heating, cooling, ventilation, illumination, etc.? Surely there are some "gray area" energy uses, but there is no reason to consider the refrigerator or television a building-energy use just because the devices are located inside the building and their electricity is combined with the electricity to power the lights and possibly, water heating, space heating, and ventilation. Reading meters is too handy and too simple a way to understand building energy use.]
Any "point system" can be gamed to achieve a selected target score. It is widely believed that consultants are hired to find the lowest cost set of points to achieve a particular LEED target -- certification or rating. Adding minimum requirements can help mitigate the "gaming" problem but won't eliminate it. Nor will it ensure that all aspects of a healthful building are well-covered.
Design is always about trade-offs. A clear definition of the criteria and consistent application of them in making design decisions is one of our long-argued viewpoints. See for example, many of our articles reflect this perspective, Check them out by clicking on the links to articles, IAQ, and sustainability.
Your feedback is always welcome.
You can also subscribe to our fee eUpdates at the link in the upper right hand corner of the home page.
How to Rebuild Architecture
Op-Ed in the New York Times, 16 December 2014
"In architecture, everyone’s a critic. One of us, Steven, was recently driving down Elliott Avenue in Charlottesville, Va., his hometown, with his 88-year-old mother. They passed a house designed and built by architecture students at the University of Virginia. To Steven, an architect, this model for affordable housing — a tough pair of stacked boxes, sheathed in corrugated metal — was a bold design statement. But to his mother’s eye, the house was a blight on the landscape, an insult to its historic neighbors."
Click here to read the full article
The NYT op-ed piece correctly identifies many of the underlying issues that separate architects from the building needs of the vast majority of people. But architecture (with a capital A) has always been primarily for the rich, and, occasionally for more of the "common" folk when public and institutional support enables it.
There are a few examples of architects whose work and lives were dedicated to the satisfaction of the building needs of ordinary people. I was fortunate enough to know and work with a couple of them. Sandy Hirshen (1935-2013) designed only "socially-relevant" buildings; he exemplifies the best possible antidote to the basic problem highlighted in the NYT op-ed. His obit summarizes his life here.
Hirshen's work is presented in part in the book: Toward an architecture of conscience. Unfortunately it is now out of print, but a few copies can be found by searching the web -- e.g., http://www.amazon.com/Toward-Architecture-Conscience-Professional-Colleagues/dp/B0042AQL9I or http://www.abebooks.com/Architecture-Conscience-Work-Sandy-Hirschen-Partners/3905665443/bd and http://www.stoutbooks.com/cgi-bin/stoutbooks.cgi/85222.
Hirshen was not only a socially-responsible architect, but also an excellent designer, as a review of his work reveals. Beyond his professional skills, Sandy was a gentle and warm human being who had little patience for bureaucratic time-wasting and impersonal institutional forms.
Hirshen served a heart attack-shortened tenure as Chairman of the Department of Architecture at UC Berkeley in 1982-3. In that role he enabled me to offer the course "Building Ecology" for the first time, (simultaneously taught in the Environmental Studies program at UC Santa Cruz).
Another example of an architect with a social conscience manifested in his work, not so much as a designer but rather as a philosopher of housing and the relationship between people and their communities, is John F. C. Turner. His work is nicely summarized here. He radically transformed government attitudes toward "invasion barrios" in Latin America, and framed an approach to the relationship between people and their housing that put the occupants first. His philosophy is articulated in his book Housing by People and in the volume he edited with several colleagues, Freedom to Build. Both are still in print and widely available.
His philosophy is often summarized as follows: 'People are most satisfied with their housing when they are able to control those aspects most important to them.' He viewed this as applicable not only to housing but to most of the important aspects of our lives.
He also argued that governments that cannot or will not provide housing for people should get out of the way of people's efforts to provide their own housing. I was able to work with him (in the early 1970s) advising the government of Mexico's Federal District (Mexico City) about the large self-built barrios there. We attempted to encourage the government to support the efforts of people to provide for their own housing needs by legalizing their tenancy and providing essential services (water, electricity, sewage, and roads).
In the end, not all of us who study architecture go on to design McMansions and other monuments for the rich, but in the end, we serve our clients and do not always have the choices available that we would like. Turner and Hirshen represent two paths architects have chosen to serve the needs of people who cannot afford to hire architects to design their homes and other buildings.
Fungal secondary metabolites as harmful indoor air contaminants
Extremely important: newly published article by J David Miller and David R. McMullin, “Fungal secondary metabolites as harmful indoor air contaminants: 10 years on.” Appl Microbiol Biotechnol, DOI 10.1007/s00253-014-6178-5. For me personally, the paper makes a strong case for the link between airborne chemicals and their relationship to moldy buildings and human health.
Increases the already strong evidence that damp buildings are risky.
Abstract “From the epidemiological studies conducted on the
effect of mould and dampness on health a decade ago, the role
of toxin-producing fungi in damp and mouldy buildings involved
opinion more than evidence. Very little was known
about the metabolites that were produced by the fungi that
grew on damp building materials, and almost nothing had
been reported on their occurrence in buildings. As a consequence,
the focus was on speculations involving the fungal
toxins that occur in agriculture. Over the past decade, particularly
in the last 5 years, considerable progress has been made
concerning the relevant toxins from fungi that grow on damp
building materials. This paper summarizes the available data
on the low-molecular-weight toxins reliably known from fungi
common on damp building materials, the toxins that have
been measured on mouldy building materials and the new
understanding of the role that they play in the documented
health effects of individuals living and working in damp and
from the Conclusions:
“‘nontoxic strains’ of S. chartarum sensu lato were producing
atranones which, although are not cytotoxic, are potently inflammatory
(Rand et al. 2006).”
“The development of high-resolution LC-MS/MS methods
has allowed the determination of fungal toxins on building
materials (Nielsen and Frisvad 2011) and in settled dusts (e.g.
Täubel et al. 2011).”
“Finally, a diverse array of metabolites from
fungi common on building materials and triple-helical glucan
have been tested for their effects on lung biology in relevant
animal models. These have revealed that toxin doses that could
be achieved in damp residential housing modulate genes that
are in asthma pathways.”
“The next decade of research will illuminate the significance of this information.”
State of California Releases an Important New Green Building Document CALGreen
The State of California Department of General Services released their policy that provides direction to state agencies that build, lease and operate state buildings, on reducing indoor pollutant levels and ensuring healthful indoor environments for occupants in new, renovated, leased, and existing state buildings, as directed in Governor’s Executive Order B- 18-12 and the Green Building Action Plan.
To read more about and download the document, click here.
Indoor Environment and indoor microbiome
Check out our new feature full of resources for studying the indoor microbiome here.
We will be adding resources to help researchers and professionals who want to study the indoor microbiome with an emphasis on culture-independent methods. We will share the results of our work during the past three years with funding from the Alfred P. Sloan Foundation through the microBEnet project at the University of California.
Our site will supplement (and complement) the microbe.net web site with information intended primarily for those who want to understand the indoor microbiome as part of the building as an ecosystem.
Nothing exemplifies the building as an ecosystem or the usefulness of the construct "building ecology" better than the complex dynamics of the built environment and the indoor microbiome. We hope this additional resource will assist those eager to advance our understanding of the indoor microbiome as a "normal" and important (essential?) part of the indoor environment.
Please send us your comments and suggestions, references, and other resources you would like us to share with other visitors to our site.If you haven't signed up yet for our eUpdates, a newsletter that will let you know when new resources are added, you can do so at the link at the top of the right hand column of this page.
Indoor Environment and indoor microbiome database -- available for free download.
More than 360 articles that contain information on the indoor microbiome and the indoor environmental conditions reported by the authors. Full abstracts are included. The database is in MS Access format and simple or complex queries can be made using the database in Access. We are looking for ways to make it more widely available. It was supported by the Alfred P. Sloan Foundation's grant to UC Davis' microBEnet project, Jonathan Eisen PI. We also have prepared a How-to file for those not familiar with constructing searches in databases. It is also downloadable. You can downloaded it from the article entitled "How to use the Indoor Environment-Indoor microbiome database."
Click here to download the database
Click here to download the how-to file
Click here to download the database curation process
Click here to get the spreadsheet version
Click here for Bibliographic info with abstracts_in pdf_140619
UPDATE Do mold and/or dampness "cause" asthma or allergic responses?
A recent paper by Choi et al (as a belated tail to the tale of the Swedish Dampness and building health (DBH) study, claims to provide further evidence of a lack of connection between mold exposure and asthma outcomes. (Choi, H., Byrne, S., Larsen, L. S., Sigsgaard, T., Thorne, P. S., Larsson, L., Sebastian, A. and Bornehag, C.-G. (2014), Residential culturable fungi, (1-3, 1-6)-β-d-glucan, and ergosterol concentrations in dust are not associated with asthma, rhinitis, or eczema diagnoses in children. Indoor Air, 24: 158–170. doi: 10.1111/ina.12068).
If you read the paper, also read all three letters to the editor.
Rylander, R. (2014) Fungi in homes - how do we measure? Indoor Air 24, 221-222
Choi, H., Thorne, P.S., Sigsgaard, T., Bornehag, C.G. (2014) Response to Rylander. Indoor Air 24, 223-224
Miller, J. David: Re: Choi et al. Indoor Air 24:158, Indoor Air 24:221
Also read the earlier publicaiton on the DBH study:
Bornehag, C. G., Sundell, J., Bonini, S., Custovic, A., Malmberg, P., Skerfving, S., Sigsgaard, T. and Verhoeff, A. (2004), Dampness in buildings as a risk factor for health effects, EUROEXPO: a multidisciplinary review of the literature (1998–2000) on dampness and mite exposure in buildings and health effects. Indoor Air, 14: 243–257. doi: 10.1111/j.1600-0668.2004.00240.x
There is another view held by the majority of researchers that dampness and mold are associated with asthma and allergy and that efforts to control moisture are essential and of great health importance..
We are hoping to start a dialogue on this subject here and solicit your comments, relevant references, and suggestions for improving the dialogue.
Please send your comments and we will post them in a thread on-line so that the discussion can be an open one.
NPR Animation of the Human Microbiome
A video from NPR about the human microbiome that is worth taking a look at.
Quick tip: Why do people living in damp buildings get sick? Is it the mold, the bacteria, or the combination?
The scientific evidence for a connection to moisture is the strongest. There is some evidence for certain species of mold and bacteria but it is generally far weaker for mold and bacteria. An exception, of course, is Legionella p, the cause of Legionnaire's Disease, but exposure to Legionella p. may not be dominated by bacteria found in the air. There is increasing evidence that molds and bacteria are involved together, not as separate "causal factors." Scientific studies that look for associations between only mold or only bacteria may not find strong associations. Moisture is clearly relevant to the microbial exposures causing the reported health effects.
Quick tip: What is the biggest mistake have we made over the past 30-40 years that we should not repeat if possible?I think it may be the separation of ASHRAE Standard 62 (Ventilation and IAQ) and Standard 55 (thermal comfort). Both IAQ and thermal comfort are affected by and ought to be addressed by the same building design and operational solutions. ASHRAE Guideline 10-2011 tries to get at these connections and interactions for the first time anywhere, well, except for papers I wrote a long time ago. ASHRAE Guideline 10, now available for purchase on the Publications
page of the ASHRAE web site, brings together a lot of what we know about the interactions and also discusses interactions with light and noise. There is far less known than we would like, but far more known than we tend to reflect in our standards, codes, and practices. If you know of some other connections, please send us an email. We will be grateful for your help.
ASHRAE Indoor Air Quality IAQ Design Guide Now Available for Free
The American Society of Heating, Refrigerating and Air Conditioning Engineers (ASHRAE) is now making the IAQ design guide and all of its reference materials available to the public at no cost through its web site.
The Indoor Air Quality Guide: Best Practices for Design, Construction and Commissioning is designed for architects, design engineers, contractors, commissioning agents, and all other professionals concerned with indoor air quality.
Click here for more information.
Microbiology of the built environment
Everywhere we turn there are microbes (living organisms so small we cannot see them without magnification): in our cars, houses, offices, water pipes, and in every nook and cranny of our bodies. Most are harmless, but some can make us sick or cause other damage. Some even play a role in protecting us and our creations from the depredations of others. Most of these microbes are still unknown and uncharacterized.
Over the last 20-30 years scientists have made revolutionary progress in understanding microbes in so-called “natural” systems. We have studied microbes in oceans, soil, and hotsprings, as well as those that live on and inside plants and animals. Little attention however has been paid to the microbes that live in the “unnatural” indoor world around us: in our buildings, planes, trains, and cars, where most of us spend more than 90 percent of our lives. These are the microbes of the “built environment”.
Thanks to continuing advances in DNA sequencing technology, and a recent initiative by the Alfred P. Sloan Foundation, this gap in knowledge is beginning to be addressed. The effort to better understand the built environment has implications for engineering and architecture, biodefense and forensics, and has even produced the concept of probiotics for buildings.
Building Ecology - A short course
It is common to assume that buildings are simply inanimate physical entities, relatively stable over time. This implies that there is little interaction between the triad of the building, what’s in it (occupants and contents), and what’s around it( the larger environment). We commonly see the overwhelming majority of the mass of material in a building as relatively unchanged physical material over time. In fact, the true nature of buildings can be viewed as the result of a complex set of dynamic interactions among their physical, chemical, and biological dimensions. Buildings can be described and understood as complex systems. Research applying the approaches ecologists use to the understanding of ecosystems can help increase our understanding. “Building ecology “ is proposed here as the application of those approaches to the built environment considering the dynamic system of buildings, their occupants, and the larger environment. Read more...
Total Volatile Organic Compounds (TVOC) has a long history as a metric for determining the acceptability of the emissions of VOCs from building products and furnishings. The first significant program to rely on a TVOC criterion was the Carpet & Rug Institute’s (CRI) Green Label Program that evolved out of the Carpet Policy Dialog between the carpet industry and the US EPA. The TVOC criterion was later incorporated into the U.S. Green Building Council’s LEED rating systems and was adopted by the commercial furniture industry. More recent VOC emission test method and acceptance standards have focused instead on individual VOCs that may pose health hazards to individuals at low concentrations. Examples of such programs in North America are the California Department of Health Services' Standard Practice (a.k.a. Section 01350), which recently was revised to Standard Method Version 1.1, and CRI’s Green Label Plus program. TVOC values are still reported, but pass/fail determinations are based on the emission levels of individual compounds of concern. There is an urgent need to expand such determinations of acceptability beyond a select number of individual VOCs to encompass the broader range of chemical emissions that may impact health. TVOC is again being proposed to fill this gap and may be appealing to many because of its presumed simplicity. In my opinion, we should avoid this temptation and move on the more difficult, but certainly achievable, task of focusing on the toxicity of individual compounds. The following are my primary arguments against the use of TVOC as a Pass/Fail metric. Read more...
|Energy Principles in Architectural Design
By Ed Dean was published in 1981 by the California Energy Commission to provide a basis for California’s licensed architects to learn about energy. The California State Board of Architectural Examiners was considering a continuing education requirement for license renewal, and it was thought that the guide could be the basis for the exam. Read more...
If outdoor ozone levels are related to SBS symptom prevalence in a building, would it be wise to install filters to remove the ozone entering the building? If using synthetic fiber filters further increased SBS symptom prevalence as outdoor ozone levels increased, would you want to use some different material for your building's particle filters?
Recently published research on the results suggest that it may reduce SBS symptom rates if you reduce ozone remove ozone from outdoor air.
Sustainable buildings are more than an assortment of "green building" features. Building design and actual performance must be compared to benchmarks or targets for a truly sustainable environment in terms of resource consumption and pollution emission.
California Greenhouse Gas Tool for Buildings
California's Greenhouse Gas (GHG) tool for California is now available on the web -GHG Tool for Buildings in California. The tool is publicly available and free for download.
This is a major step forward, the first tool that provides time- and weather-resolved GHG emissions calculations. Read more...
IAQ and Plants
| The idea that plants clean indoor air is a sad, continuing saga fed by
bad science, commercial interests, and wishful thinking. I published an
article in the Indoor Air Bulletin
on the subject in 1992 (available on this web site) that provides some details.
Take home message:
1. Don't use plants to improve IAQ. They don't. If anything, they pose risks to good IAQ.
2. There is no credible scientific evidence that plants improve IAQ. The planting media has been hypothesized to be responsible for pollutant removal in some studies. The planting media alone can be expected to contribute to a limited reduction in some airborne chemical concentrations.
3. Most advocates of indoor plant use have been funded by or are themselves providers of plants or supporting systems.
4. If plants are used indoors for aesthetic reasons, there should be extra care to avoid moisture problems or problems with fertilizers and pesticides, all known sources of indoor air quality and health problems.Read more...
